XL6009 DC-DC Boost Step Up Module

DescriptionReviewsXL6009 DC-DC Boost Step Up Module Price in PakistanXL6009 is a high-performance 4A switch current boost (BOOST) module.The module uses the second-generation high-frequency switching technology XL6009E1 as the core chipFar more than the first generation of technology performance LM2577.The XL6009 boost module features lower cost and superior performance, and the LM2577 module is about to be eliminated.Wide input voltage 3V ~ 32V, the best operating voltage range is 5 ~ 32V;Wide output voltage 5V ~ 35V;Built-in 4A high efficiency MOSFET switch, the efficiency of up to 94%; (LM2577 current of only 3A)High switching frequency of 400KHz, you can use a small capacity of the filter capacitor that can achieve very good results, smaller ripple, smaller. (LM2577 frequency is only 50KHz)Input Range: 3V to 32VOutput Range: 5V ~ 35VInput Current: 4A MaxConversion Efficiency: <94%Switching Frequency: 400KHzOutput Ripple: 50mV (the higher the voltage, the greater the current, the greater the ripple)Operating Temperature: -40 ° ~ 85 °Dimensions: 43mm * 21mm * 14mm (L * W * H) Package Includes:1 x XL6009 DC-DC Boost Step Up ModuleCategories: Modules, Power, Voltage ConvertersTags: Boost, Step Up, XL6009
